OEM Double Loop Rebar Tie Wire Factory

Double loop rebar tie wire is a precision-formed fastening solution designed to secure reinforcing steel bars (rebar) in concrete construction. Unlike single-loop or plain wire alternatives, the double loop configuration creates a self-locking mechanism that resists slippage under vibration and load, making it ideal for high-rise buildings, bridges, and infrastructure projects where long-term structural integrity is critical.

Manufacturing begins with cold-drawn low-carbon steel wire, typically grade SAE 1006 or equivalent, selected for its balance of tensile strength (400–550 MPa) and ductility. The wire undergoes inline annealing to reduce internal stresses before being fed into high-speed forming machines that simultaneously bend and interlock two loops per tie. This process ensures dimensional consistency—loop diameter typically 6–8 mm, leg length 75–150 mm—critical for compatibility with automatic tying tools and manual application in congested rebar cages.

Technical Specifications and Material Options

Wire diameter directly influences holding strength and installation speed. Common sizes range from 0.8 mm to 1.6 mm, with 1.0 mm and 1.2 mm being most prevalent in commercial construction. Thicker wires (1.4–1.6 mm) are used in seismic zones or heavy-load applications where higher pull-out resistance is required, though they demand more manual force to install. The wire’s zinc coating—usually electrogalvanized at 8–12 µm thickness—provides short-term corrosion resistance during formwork and pouring; hot-dip galvanizing (40–60 µm) or epoxy coating is available for prolonged exposure in marine or industrial environments.

Manufacturing Process and Quality Control

Production occurs on dedicated high-speed lines where wire is continuously drawn, cleaned, annealed, coated, and formed without intermediate spooling to minimize handling defects. Each tie undergoes inline vision inspection to verify loop symmetry, leg length, and absence of wire splits or cracks—defects that could compromise load-bearing capacity. Sampling follows ISO 9001 protocols: tensile strength tested every 2 hours, coating thickness verified via XRF daily, and dimensional accuracy checked via laser gauging on 1% of output.

Packaging is designed to prevent tangling and deformation during transit. Ties are typically bundled in groups of 50 or 100 using biodegradable paper bands, then packed into corrugated cartons with internal dividers. For automated rebar tying systems, wire is supplied on spools or in side-feeding drums engineered to maintain consistent tension and prevent birdnesting. Moisture-barrier liners and desiccant packets are included in humid climates to preserve coating integrity until point of use.

Applications in Structural Concrete Work

The double loop design excels in scenarios requiring rapid, repeatable connections where access is limited—such as vertical column cages, slab-on-grade mats, or precast element assembly. Because the loops interlock when tensioned, they maintain holding force even if the installer cannot achieve perfect twist tension, reducing reliance on operator skill. This is particularly valuable in large-scale projects with rotating crews or where weather conditions affect manual dexterity.

In seismic retrofitting, where existing structures are wrapped with new rebar jackets, the double loop’s resistance to cyclic loading prevents gradual loosening over time—a known failure point with plain wire ties under repeated stress. Similarly, in tunnel linings and wastewater tanks exposed to chlorides or sulfates, the combination of proper coating and mechanical lock extends service life by minimizing corrosion-induced weakening at the tie point.

Customization and Ordering Considerations

OEM production allows full customization of wire diameter, coating type, loop geometry, and leg length to match specific tying tools or project specifications. For example, contractors using battery-powered tier tools may require shorter leg lengths (75–100 mm) to fit within the tool’s nose geometry, while manual tiers in deep foundations benefit from longer legs (120–150 mm) for easier handling. Coating selection should align with the concrete’s expected pore solution pH and chloride exposure class per ISO 9223 or ASTM G108.

Lead times depend on coating complexity and order volume. Standard electrogalvanized ties in common sizes typically ship within 10–15 working days after drawing approval. Hot-dip galvanizing or epoxy coating adds 5–7 days due to additional processing and curing. Minimum order quantities are generally 50 kg per SKU, though trial runs of 10–20 kg are available for validation. Technical documentation—including material certificates, coating reports, and ISO compliance statements—is provided with each shipment.

Request Technical Specifications or Quote
